About
Description
High Efficient Industrial Power Supply 76.8W, 48 VDC in slimline package.
- Output: 48VDC, 1.6A (76.8W)
- High efficiency 91% and low power dissipation
- 150% peak load capability
- Built-in active PFC function, PF>0.93
- Protections: Short circuit / Overload / Over voltage / Over temperature Cooling by free air convection
- Can be installed on DIN rail TS-35/7.5 or 15
- UL 508 (industrial control equipment) approved EN61000-6-2(EN50082-2) industrial immunity level
- Built-in DC OK relay contact
- 100% full load burn-in test
- 3 years warranty
Description
High Efficient Industrial Power Supply 76.8W, 48 VDC in slimline package.
- Output: 48VDC, 1.6A (76.8W)
- High efficiency 91% and low power dissipation
- 150% peak load capability
- Built-in active PFC function, PF>0.93
- Protections: Short circuit / Overload / Over voltage / Over temperature Cooling by free air convection
- Can be installed on DIN rail TS-35/7.5 or 15
- UL 508 (industrial control equipment) approved EN61000-6-2(EN50082-2) industrial immunity level
- Built-in DC OK relay contact
- 100% full load burn-in test
- 3 years warranty
Dureco
by
Dureco
Power Supply SDR-75-48
- Regular price
- $76.00
- Sale price
- $76.00
- Regular price
-
Shipping calculated at checkout.
