TPU Flexible 3D Printing Filament

Wear and chemicals resistant.

  • The TPUs are highly resistant to chemical agents, wear-proof and with good elastic comeback.
  • FLEXMARK 9 = 90 Shore A, is the stiffest of all the Flexs, and lets you print as usual.
  • High elastic return, meaning the object will come back to its shape very quickly.
3D printing Flexible filament TPU engineering
Printing Suggestions

Suggested printing specification

  • Extruder temperature - 220 C° +10/-5
  • Bed temperature: cold to 45C°
  • Build surface material: glass, blue tape, kapton tape, buildtak, PEI
  • Print speed: 25-35 mm/s
  • Fan: 0-50%
  • Minimum nozzle dia: 0.30 mm
Specifications

Material properties

  • Diameter: 1.75mm
  • Shore Hardness: 93 shA (ISO 62)
  • Density: 1.24 g/cm3 (ISO 1183)
  • Elongation at break: 600 % (ISO 37)
  • Compression set (70°C): 45 % (ISO 815)
  • Tensile strain: 55 MPa (ISO 37)
  • Abrasion loss: 30 mm3 (ISO 4649)
  • Charpy Impact at 23°C: No Break kJ/m2 (ISO 179)
  • Charpy Impact at -30°C: No Break kJ/m2 (ISO 179)

Datasheet

Description
Features

TPU Flexible 3D Printing Filament

Wear and chemicals resistant.

  • The TPUs are highly resistant to chemical agents, wear-proof and with good elastic comeback.
  • FLEXMARK 9 = 90 Shore A, is the stiffest of all the Flexs, and lets you print as usual.
  • High elastic return, meaning the object will come back to its shape very quickly.
3D printing Flexible filament TPU engineering
Printing Suggestions

Suggested printing specification

  • Extruder temperature - 220 C° +10/-5
  • Bed temperature: cold to 45C°
  • Build surface material: glass, blue tape, kapton tape, buildtak, PEI
  • Print speed: 25-35 mm/s
  • Fan: 0-50%
  • Minimum nozzle dia: 0.30 mm
Specifications

Material properties

  • Diameter: 1.75mm
  • Shore Hardness: 93 shA (ISO 62)
  • Density: 1.24 g/cm3 (ISO 1183)
  • Elongation at break: 600 % (ISO 37)
  • Compression set (70°C): 45 % (ISO 815)
  • Tensile strain: 55 MPa (ISO 37)
  • Abrasion loss: 30 mm3 (ISO 4649)
  • Charpy Impact at 23°C: No Break kJ/m2 (ISO 179)
  • Charpy Impact at -30°C: No Break kJ/m2 (ISO 179)

Datasheet

TreeD by TreeD

FLEXMARK 9 – 1,75ø – 500gr Spool

Regular price
$79.00
Sale price
$79.00
Regular price
Shipping calculated at checkout.
