Description
DDR-120 series is a 120W DIN Rail type DC-DC converter with main features including DIN rail-type easy installation, ultra slim width (32mm), 2:1 wide input voltage, fan-less design, -40 ~ +70ºC wide operating temperature, 4KV dc I/O isolation, 150% peak load, adjustable output voltage and full protective functions. Suitable applications include DC buck/boost regulator, boost voltage from solar system to 48VDC to power PoE equipment.
  • Input voltage: 12VDC (9~18VDC)
  • Output: 48 VDC, 2.1A (100.8W)
  • Ultra slim: Only 32mm wide
  • 2:1 input range
  • Wide operating temperature (-40 ~ +70ºC)
  • 150% peak load capacity
  • Adjustable output voltage
  • 4kVDC I/O isolation
  • Protection: Short circuit / Overload/ Over voltage/ Over temperature/ Input reverse polarity/ Input under voltage protection
  • DC output adjustable (+15%)
  • Complies with EN50155 & EN45545-2 railway standards
      Description
      DDR-120 series is a 120W DIN Rail type DC-DC converter with main features including DIN rail-type easy installation, ultra slim width (32mm), 2:1 wide input voltage, fan-less design, -40 ~ +70ºC wide operating temperature, 4KV dc I/O isolation, 150% peak load, adjustable output voltage and full protective functions. Suitable applications include DC buck/boost regulator, boost voltage from solar system to 48VDC to power PoE equipment.
      • Input voltage: 12VDC (9~18VDC)
      • Output: 48 VDC, 2.1A (100.8W)
      • Ultra slim: Only 32mm wide
      • 2:1 input range
      • Wide operating temperature (-40 ~ +70ºC)
      • 150% peak load capacity
      • Adjustable output voltage
      • 4kVDC I/O isolation
      • Protection: Short circuit / Overload/ Over voltage/ Over temperature/ Input reverse polarity/ Input under voltage protection
      • DC output adjustable (+15%)
      • Complies with EN50155 & EN45545-2 railway standards
          Some heading
          Some text
          Dureco by Dureco

          DC to DC Converter DDR-120A-48 12 to 48

          $154.00
          $154.00
          Shipping calculated at checkout.
