The FIRST and ONLY Carbon Fiber Filament

Part of Nylon Carbon Fiber Filament Technical line.

• Carbonio Nylon. TreeD uses only fibers, not powders. Because it’s not “Powder Carbon” but “Fiber Carbon”.
• 100% tested and working. After months of development, Carbonio is ready to be easy printed.
• It is ideal for high-end mechanical applications, thanks to its high tensile modulus.
• Its very low hygroscopy means you DO NOT have to dry the filament anymore before using it.

Suggested printing specification

• Build surface material: kapton tape with glue, buildtak with glue

CARBONIUM Tips & Tricks

0.5 mm is the minimum diameter of the nozzle with carbon fibers reinforced. Carbon fibers are abrasive, we suggest to use a nozzle in hardened or tempered metal, like Widia, or wear resistance internal surface, like ceramics or other. NO tefloned surface!

Material properties

• Diameter: 1.75mm
• Density: 1.07 g/cm3 (ISO 1183)
• Water absorption: 1.1 % (ISO 62)
• Tensile modulus: 8000 MPa (ISO 178)
• Melting point: 178°C (ISO 3146)
• Flexural Modulus: 6800 MPa (ISO 178)
• Stress at break: 110 MPa (ISO 527-2)
• Volume Resistivity: 1,00 e+11 ohm/cm ( ISO 60093)

Datasheet
